Wharfedale Pro AEROLINE VOCAL Wireless Microphone

Aeroline vocal

For the voice !

Made specifically for solo vocal performances the Aeroline Vocal Wireless mic system delivers perfect vocal clarity over long distances, in a simple to use package.

A specially designed microphone capsule captures the detail and warmth of the voice, ensuring that the system gets the best possible quality audio input.

This signal is then transmitted to the ‘small footprint’ receiver with dual antennae using True Diversity technology. This results in a system which works over long distances without drop-outs.

Unique to products at this price point are the backlit LCD displays on both the mic and the receiver. This makes setup and control simple.

With its high quality capsule, superb long range performance and easy operation, Aeroline Vocal delivers everything the vocalist or presenter needs.

Backlit LCD’s on mic and receiver. Easy to see on-stage.
High quality vocal microphone capsule design
True diversity system signal stability over long distances
2 models available
200 channels – 650-700 MHz
81 channels – 863-865 MHz
Easy to setup with infrared syncing

Capsule – made for the voice

The moving coil capsule is robust and durable. It is tough enough to ensure drops and road-damage.

The response pattern is super cardioid which gives good upfront coverage while rejecting from the rear. This reduces the chance of feedback.

For singers, the capsule delivers a warm tone and the internal electronics have been prepared to handled the highest of dynamics.

For Presenters, the well-tuned frequency response of the capsule will ensure that your audience will hear each nuance and the finer detail of your voice.

What’s in the box ?

Receiver : 1 pc

Handheld wireless mic : 1 pc

Power supply : 1 pc

User manual : 1 pc

Antennae : 2 pcs

SPECIFICATIONS

Included items	AEROLINE VOCAL	AEROLINE VOCAL
Working frequency:	863-865 MHz	650-700 MHz
Modulation mode:	UHF	UHF
Channels:	81	200
Operating distance:	about 120m (line of sight)	about 120m (line of sight)
RF generator mode:	PLL Frequency Synthesizer	PLL Frequency Synthesizer
RF bandwidth:	2 MHz	96 MHz
RF frequency precision:	+/- 10 ppm	+/- 20 ppm
Audio frequency response:	60 Hz-15 KHz (100 mV input )	60 Hz-15 KHz (100 mV input )
SNR:	> 98 dB (A weighted)	> 98 dB (A weighted)
THD:	<1% / 1 KHz (300 mV output )	<1% / 1 KHz (300 mV output )
Transmitter
Dynamic range:	> 95 dB	> 90 dB
Output Power:	30 mW	30 mW
Display:	LCD	LCD
Current consumption:	<120 mA / 3 v	<120 mA / 3 v
Power supply:	1.5 x AA or AA rechargeable batteries	1.5 x AA or AA rechargeable batteries
Transducer pickup head:	Moving coil	Moving coil
Pickup mode:	Super cardioid	Super cardioid
Sensitivity:	<- 55 dB ± 3 dB (0dB = 1 V / Par at 1 KHz)	<- 55 dB ± 3 dB (0dB = 1 V / Par at 1 KHz)
Maximum SPL:	> 105 dB SPL	> 105 dB SPL
Battery life:	About 8 hours(related to the battery quality)	About 6 hours(related to the battery quality)
Receiver
Sensitivity:	103 dBm (20 dB SINAD)	103 dBm (20 dB SINAD)
Harmonic distortion:	<0. 5% / 1 KHz (200 mV output)	<0. 5% / 1 KHz (300 mV output)
Display:	LCD	LCD
Audio outputs:	Balanced XLR plus 1/4” jack	Balanced XLR plus 1/4” jack
Power supply:	12 V / 500 mA	12 V / 500 mA

New

Click to enlarge

Order on WhatsApp

Call 0740418548

Add to wishlist

Categories: Microphone, Wireless Mic

Description

Included items	AEROLINE VOCAL	AEROLINE VOCAL
Working frequency:	863-865 MHz	650-700 MHz
Modulation mode:	UHF	UHF
Channels:	81	200
Operating distance:	about 120m (line of sight)	about 120m (line of sight)
RF generator mode:	PLL Frequency Synthesizer	PLL Frequency Synthesizer
RF bandwidth:	2 MHz	96 MHz
RF frequency precision:	+/- 10 ppm	+/- 20 ppm
Audio frequency response:	60 Hz-15 KHz (100 mV input )	60 Hz-15 KHz (100 mV input )
SNR:	> 98 dB (A weighted)	> 98 dB (A weighted)
THD:	<1% / 1 KHz (300 mV output )	<1% / 1 KHz (300 mV output )
Transmitter
Dynamic range:	> 95 dB	> 90 dB
Output Power:	30 mW	30 mW
Display:	LCD	LCD
Current consumption:	<120 mA / 3 v	<120 mA / 3 v
Power supply:	1.5 x AA or AA rechargeable batteries	1.5 x AA or AA rechargeable batteries
Transducer pickup head:	Moving coil	Moving coil
Pickup mode:	Super cardioid	Super cardioid
Sensitivity:	<- 55 dB ± 3 dB (0dB = 1 V / Par at 1 KHz)	<- 55 dB ± 3 dB (0dB = 1 V / Par at 1 KHz)
Maximum SPL:	> 105 dB SPL	> 105 dB SPL
Battery life:	About 8 hours(related to the battery quality)	About 6 hours(related to the battery quality)
Receiver
Sensitivity:	103 dBm (20 dB SINAD)	103 dBm (20 dB SINAD)
Harmonic distortion:	<0. 5% / 1 KHz (200 mV output)	<0. 5% / 1 KHz (300 mV output)
Display:	LCD	LCD
Audio outputs:	Balanced XLR plus 1/4” jack	Balanced XLR plus 1/4” jack
Power supply:	12 V / 500 mA	12 V / 500 mA
