FEATURES
- Bi-amplified class D powered system with 200 watts total power
- DDT compression on both power amps
- 15″ woofer with 2-3/8″ voice coil and neodymium magnet
- Woofer Servo
- Automatic equal loudness (Fletcher-Munson) compensation
- 14T 1.4″ titanium compression driver
- Peak SPL up to 120dB with music
- Combo jack 1/4″ TRS and female XLR mic
- Two 1/4″ phone jacks for link-out/direct-in capability
- 47 lbs.
SPECIFICATIONS
- Powered: Yes
- Power Configuration: Bi-amped
- LF Driver Size: 15″
- HF Driver Size: 2.38″
- Total Power: 200W
- Inputs: 1 x Combo (XLR/TRS), 1 x 1/4″ (Link)
- Outputs: 1 x 1/4″ (Link)
- Frequency Range: 58Hz-21khz (-10dB), 79Hz-17kHz (-3dB)
- Maximum Peak SPL: 120dB
- Horizontal Coverage Angle: 40 Degrees
- Vertical Coverage Angle: 90 degrees
- Enclosure Material: MDF
- Mounting Options: Floor Wedge
- Height: 17.75″
- Width: 25″
- Depth: 12.56″
- Weight: 49.82 lbs.
Dimension Packaging Weight : 30.0 kg
